Description
2023 Beta 500 RR-S
ENGINE |
CHASSIS |
||
| Type: | Single cylinder, 4 –stroke, liquid cooled, 4-valve (Titanium intake and exhaust), cooling fan, electric start. (back up kick starter as an option) | Frame: | Molybdenum steel, double cradle w/ quick air filter access |
| Bore: | 100mm | Wheelbase: | 58.7″ |
| Stroke: | 60.8mm | Seat Height: | 37″ |
| Displacement: | 477.5cc | Ground Clearance: | 12.6″ |
| Compression Ratio: | 11.86:1 | Footrest Height: | 16.3″ |
| Exhaust Valve: | Titanium Intake & Exhaust | Dry Weight: | 243 lbs (wet weight, no fuel) |
| Ignition: | Dual-Map Kokusan 200w output On-Demand Traction Control |
Fuel Tank Capacity: | 2.4 US Gallons |
| Spark Plug: | NGK LKAR8A-9 | Front Suspension: | 48 mm Sachs Open Cartridge with compression, rebound & spring preload adjustment |
| Lubrication: | Twin Oil Pumps w/Cartridge Filter & Separate Compartments For Engine & Transmission | Rear Suspension: | Aluminum Body Sachs shock w/adjustable rebound and hi/low speed compression |
| Fuel System: | 42mm Throttle Body w/Dual Injectors | Front Wheel Travel: | 11.6″ |
| Traction Control: | On-Demand w/ push of a button | Rear Wheel Travel: | 11.4″ |
| Clutch: | Wet Diaphragm-style | Front Brake: | 260 mm floating rotor |
| Transmission: | 6 Speed | Rear Brake: | 240 mm rotor |
| Final Drive: | O-ring chain | Front/Rear Rim: | 21″ (Front) 18″ (Rear) |
| Traction Control: | On-Demand with push of a button | Front/Rear Tire: | DOT Maxxis Enduro |
| Electrical: | Trail Tech Voyager GPS unit | ||
| MSRP | $11,799 | Final Gearing: | 15T Front/48T Rear (comes w/ 13T front for off-road use) |
| Destination Fee | $439.00 | ||
| *Specifications subject to change without notice. Additional information on all models including manuals,accessories and parts books are available online at www.betausa.com under SUPPORT. | |||
