Description
ENGINE TYPE: Beta Built single cylinder, 2-stroke, liquid cooled, with BPV power
valve system and counter balancer, electric start with back-up kick starter sold as an option
BORE: 73mm
STROKE: 69.9mm
DISPLACEMENT: 292.3cc
COMPRESSION RATIO: 11.55:1
VALVE TRAIN: Beta Progressive Valve (BPV)
IGNITION: AC-CDI Kokusan
SPARK PLUG: NGK GR7CI8
LUBRICATION: Electronic Oil Injection
FUEL SYSTEM: Kelhin PWK 36mm
CLUTCH: Wet Diaphragm-style
TRANSMISSION: 6 Speed
FINAL DRIVE: O-ring chain
FRAME: Molybdenum steel / Double
Cradle w/ quick air filter
access
WHEELBASE: 57.8″
SEAT HEIGHT: 35.8″
GROUND CLEARANCE: 12.6″
FOOTREST HEIGHT: 15.4″
DRY WEIGHT: 218 lbs
FUEL TANK CAPACITY: 2.3 US Gallons
FRONT SUSPENSION: 43 mm inverted front fork with adjustable dampening
REAR SUSPENSION: Steel body shock with adjustable rebound and compression
FRONT WHEEL TRAVEL: 10.6″
REAR WHEEL TRAVEL: 10.6″
FRONT BRAKE: 260 mm floating rotor
REAR BRAKE: 240 mm rotor
FRONT/REAR RIM: 21″ (Front) 18″ (Rear)
FRONT/REAR TIRE: Soft Enduro Competition
*Specifications subject to change without notice. Additional information on all models including manuals, accessories and parts books are available online at www.betausa.com under SUPPORT.
